LPS AlphaLoc Couplers

The innovative new LPS AlphaLoc couplers are unlike anything currently available on the market. Featuring a spring loaded assembly with a fast thread and locking detent, these intercooler couplers utilize a double o-ring seal and the unique design locks them harder as pressure increases. These have been hydrostatically tested up to 160 psi without leakage. Best of all, you don't need any tools for assembly or disassembly! Available now in 2", 2.5", 3", 3.5" and 4.0" with many more sizes, including coolant line sizes coming soon.

LPS AlphaLoc Coupler Features:

• 2" thru 4" Size
• Aluminum Weld Flanges
• Aluminum Collar (anodized black)
• Viton O-Rings
• 2" Wide (w/ flanges)
• 1/4 Turn Engagement
• Pressure Rating: 160 psi
• Temperature Rating: -30°F to 400°F
• Axial Flex: 10 Degrees
• Linear Movement: 0.25"
